625W Monocrystalline Solar Panel – 144 Cell | 16 Busbar High Efficiency Module

625W Monocrystalline Solar Panel – 144 Cell | 16 Busbar High Efficiency Module

Product Overview

The 625W 144-cell 16-busbar monocrystalline solar module is designed for high-performance solar power systems, delivering excellent efficiency, durability, and long-term energy yield. Built with advanced 16 busbar technology, it provides improved current collection, reduced power loss, better shading tolerance, and higher reliability for commercial and utility-scale installations.

⸻

Electrical Parameters (STC)

STC Conditions: Irradiance 1000W/m², AM 1.5, Cell Temperature 25°C

Parameter Value
Maximum Power (Pmax) 625W
Power Tolerance 0 ~ +5W
Maximum Power Voltage (Vmp) 41.0V – 42.0V
Maximum Power Current (Imp) 14.8A – 15.3A
Open Circuit Voltage (Voc) 49.5V – 50.5V
Short Circuit Current (Isc) 15.8A – 16.5A
Module Efficiency 21.5% – 22.5%
Maximum System Voltage 1500V DC
Maximum Series Fuse Rating 25A

⸻

Electrical Parameters (NOCT)

NOCT Conditions: Irradiance 800W/m², AM 1.5, Ambient Temp 20°C, Wind Speed 1m/s

Parameter Value
Pmax (NOCT) ~470W – 490W
Vmp (NOCT) ~38.0V – 39.5V
Imp (NOCT) ~12.3A – 12.9A
Voc (NOCT) ~46.0V – 47.5V
Isc (NOCT) ~13.0A – 13.8A

⸻

Temperature Coefficients

Parameter Value
Temperature Coefficient of Pmax -0.35% / °C
Temperature Coefficient of Voc -0.28% / °C
Temperature Coefficient of Isc +0.04% / °C

⸻

Mechanical Specifications

Specification Details
Cell Type Monocrystalline PERC / TOPCon (Optional)
Cell Arrangement 144 Cells (6 × 24)
Busbar Technology 16 Busbar (16BB)
Glass Type 3.2mm Tempered Low-Iron AR Glass
Frame Anodized Aluminum Alloy
Backsheet High Durability TPT / Transparent (Optional)
Junction Box IP68 Waterproof
Connector Type MC4 Compatible
Cable Length 300mm – 1200mm (Custom Available)
Dimensions Approx. 2278 × 1134 × 35mm
Weight Approx. 31kg – 35kg

⸻

Operating Conditions

Parameter Value
Operating Temperature -40°C to +85°C
Maximum Wind Load 2400 Pa
Maximum Snow Load 5400 Pa
Humidity Resistance Up to 95% RH
Fire Rating Class C (or higher depending on model)

⸻

Key Features

✅ 625W High Power Output for large solar systems
✅ 16 Busbar Technology improves efficiency and reduces internal loss
✅ 144-cell design improves performance and reliability
✅ Excellent low-light performance (morning/evening conditions)
✅ Anti-PID Technology for long-term durability
✅ IP68 Junction Box for water and dust protection
✅ Strong frame design for harsh weather environments

⸻

Applications

✔ Solar Farms / Utility Projects
✔ Commercial & Industrial Rooftop Systems
✔ Solar Mini-Grids
✔ Residential Solar Power Systems
✔ Hybrid Solar + Inverter + Battery Installations

⸻

Certifications (Optional Section for Website)

* IEC 61215
* IEC 61730
* ISO 9001 Certified Manufacturing
* ISO 14001 Environmental Standard
* PID Resistant Tested
* Salt Mist & Ammonia Corrosion Tested (Optional)

⸻

Warranty

Warranty Type Coverage
Product Warranty 12 – 15 Years
Performance Warranty 25 Years Linear Warranty
Year 1 Output Guarantee ≥ 98%
Year 25 Output Guarantee ≥ 92%

⸻
